H1664NL 4x10/100Base-Tx Transformer 350 µH With 1500 V Isolation Voltage

Product Categories
LINK-PP INT'L TECHNOLOGY CO., LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

H1664NL 4x10/100Base-Tx Transformer 350 µH With 1500 V Isolation Voltage

  • 1
  • 2
  • 3

Brand Name : LINK-PP

Model Number : H1664NL

Certification : UL,RoHS,Reach,ISO

Place of Origin : Guangdong,China

MOQ : 400/2000/10K/25K

Price : $0.06-$3.2

Payment Terms : TT,NET30/60/90 Days

Supply Ability : 3KK/Month

Delivery Time : Stock

Packaging Details : T&R

Specifications : H1664NL

P/N : LP44007NL

Measure : 28.45 mmx12.19 mmx5.71 mm

Mounting : SMD

Ethernet : 4x10/100Base-Tx

Samples : Free

Archivi Disponibili : PDF/3D/ISG/Stp/Step/Datasheet

Contact Now

H1664NL | LP44007NL Quad Port 10/100 Transformer Ethernet Magnetic Module
  • PULSE TRANSFORMER FOR GENERAL PURPOSE APPLICATION(S)
  • Coil Number: Autotransformer
  • Isolation Voltage:1500Vrms
  • Type: Surface Mounting
  • Coil Structure: Toroidal
  • 10/100 Base-T Four Port Transformer Modules
  • LP44007NL Equivalent Specifications
  • Pulse H1664NL Cross PN

H1664NL 4x10/100Base-Tx Transformer 350 µH With 1500 V Isolation Voltage

SPECIFICATIONS

Mfr Package Description ROHS COMPLIANT
REACH Compliant Yes
EU RoHS Compliant Yes
Status Active
Transformer Type PULSE TRANSFORMER
Application GENERAL PURPOSE
Isolation Voltage 1500.0 V
Manufacturer Series H1664NL Equivalent
Mounting Feature SURFACE MOUNT
Number of Functions 2
Operating Temperature-Min 0.0 Cel
Operating Temperature-Max 70.0 Cel
Physical Dimension L28.45XB12.19XH5.71 (mm)
Primary Inductance 350.0 µH
Turns Ratio (Np:Ns) 1:1
Height 5.71 mm
Length 28.45 mm
Width 12.19 mm
Additional Feature HEIGHT DIM INCLUDE TERMINALS ALSO
Equivalent part Sales LP44007NL Cross Compatible price to buy

H1664NL | LP44007NL Quad Port 10/100 Transformer Ethernet Magnetic Module
